Lower Pressure Casting Riser Tube
Name: Lower Pressure Casting Riser Tube
Composition: Silicon nitride or Alumina
Size: Can be customized according to customer requirements
Payment:
30% T/T in advance for more than USD2000, balance pay before shipment.
100% T/T payment for amount less than USD2000.
Description
Lower pressure casting riser tube is one of the key components of low pressure casting machine. During the die-casting process, the aluminum melt (temperature 700~900℃) is pressured from the riser pipe to the mold cavity every 3 to 5 minutes.
The steel riser pipe is used in the traditional production process. Due to poor thermal shock resistance, poor corrosion resistance, short service life and frequent replacement, it cannot meet the requirements of continuous and high-quality production. Silicon nitride riser tube has become an ideal material for preparing lower pressure casting riser tube due to its low thermal expansion, good thermal shock resistance, and non-stick aluminum.
Product Production Process:
1. Cold iso static pressing
2. Machining
3. Reaction sintering/air pressure sintering
Product Specification:
Performance | Parameter |
Density (g/cm3) | 3.2g/cm3 min. |
Apparent porosity (%) | 0.3% max. |
Rockwell hardness (HRA) | 93 min. |
The highest operating temperature in the air (℃) | 1400 Max. |
use temperature in protective atmosphere (℃) | 1800 |
Fracture surface energy (20℃)/(J/m2) | 133 |
Flexural strength (MPa) | 986(20℃), 485(1400℃) |
Specific heat (J/g ·K) | 0.71 |
Poisson's ratio(20℃) | 0.290 |
Thermal conductivity［W/(m·K)］ | 28.8 |
Thermal diffusion coefficient (300℃)/(cm2/s) | 0.690 |
Resistivity (Ω·m) | 1.4x105(20℃), 4x108(1050℃) |
Product Features:
1. High temperature resistance, corrosion resistance, and non-ferrous metal melt such as aluminum melt
2. Excellent thermal conductivity, strong thermal shock resistance, no explosion
3. Anti-oxidation, long service life
4. Can be made according to customer specifications
Product Application:
Lower pressure aluminum alloy casting and etc.
Product Packing:
FAQ:
Q: Samples are free?
A: Yes, we could provide samples with free of cost.
Q: How many days for sampling?
A: 7~10 days for regular size we have.
Q: How many days for production?
A: 30~60 days according to the size and quantity.
Q: Could we put our own logo?
A: Sure, customers logo can be made by laser engraved embossed transfer printing.
