product advantages
Resinoid grinding wheels have several unique characteristics that set them apart from other types of grinding wheels.
Abrasive grains
The abrasive grains used in resinoid grinding wheels are typically aluminum oxide, silicon carbide, or a combination of the two. These grains are highly durable and can withstand the high heat generated during the grinding process.
Resin bond
The bond that holds the abrasive grains together in resinoid grinding wheels is made of a synthetic resin material. This resin bond provides excellent elasticity and helps to reduce vibration during the grinding process.
Heat resistance
Resinoid grinding wheels are highly resistant to heat. They can operate at high speeds and temperatures without losing their shape or degrading the quality of the finished product.
Versatility
Resinoid grinding wheels can be used for a wide range of applications, including precision grinding, surface grinding, and cylindrical grinding. They are also suitable for both dry and wet grinding.
Cutting WheelsRenwa cutting wheels are engineered to deliver clean, straight cuts with minimal burr formation and reduced heat generation. Through optimized grain distribution and resin bonding technology, the
Add to Inquiry
Grinding Wheel For RailThe Grinding Wheel for Rail is a specialized abrasive tool engineered for professional railway maintenance, rail surface conditioning, and track restoration operations. Designed to withstand high
Add to Inquiry
Nuts WheelRenwa Abrasive offers high-efficiency nut wheels designed for heavy-duty tool sharpening, suitable for Blanchard-type rotary surface grinders. Its robust nut insertion mechanism ensures high
Add to Inquiry
Grinding Disc For ShipyardGrinding disc for shipyard widely used in surface grinding of various metal materiald and edge angle, chamfer, clear the rough weld of the joints, grinding and metal surface defect repair work.
Add to Inquiry
Depressed Center Cut Off WheelsOur depressed center cut off wheels are made of resin as bond binder, which has a good cutting performance when cutting the alloy steel, stainless steel and other hard-machined material. The cutting
Add to Inquiry
Rail Cut Off WheelsName: Rail Cut Off Wheels. Composition: Composite raw material. Size: Can be customized according to customer requirements. Payment:. 30% T/T in advance for more than USD2000, balance pay before
Add to Inquiry
Super Thin Cutting WheelsName: Super Thin Cutting Wheels. Composition: Glass fiber mesh,Abrasives. Size: Can be customized according to customer requirements. Payment:. 30% T/T in advance for more than USD2000, balance pay
Add to Inquiry
Green Silicon Carbide Flexible Grinding WheelsName: Green Silicon Carbide Flexible Grinding Wheels. Composition: Green Silicon Carbide. Size: Can be customized according to customer requirements. Payment:. 30% T/T in advance for more than
Add to Inquiry
Heavy Duty Grinding WheelHeavy duty grinding wheel has the characteristics of high strength, high density, high hardness, high grinding ratio and high efficiency. Depending on the kinds of steel, the work load of grinding
Add to Inquiry
Products production process
Raw Material Selection
The first and foremost step in the production process of a resinoid grinding wheel is the selection of raw materials. Abrasive grains, resins, and other fillers are selected based on their quality and characteristics.
Weighing and Mixing
After the selection of raw materials, these materials are then weighed and mixed in an appropriate and consistent ratio. The mixing is done by a mixing machine, which helps to ensure that the ingredients are thoroughly combined.
Molding
Once the mixture is ready, it is then molded into a specific shape and size. The mold used can vary in size and shape, depending on the desired end product.
Curing
After molding, the resinoid grinding wheel is then cured under high temperatures and pressure. The curing process can take several hours or even days, depending on the specific type of resin used.
Surface Treatment
Once the wheel has been cured, it undergoes surface treatment. This includes processes such as grinding and polishing, which helps to ensure that the surface of the wheel is smooth and even.
Inspection and Testing
Once the surface treatment is complete, the wheel undergoes stringent inspection and testing. This is done to ensure that the wheel meets the required standards of quality, strength, and durability.
Packaging and Shipping
The final step in the production process of resinoid grinding wheels is packaging and shipping. The wheels are carefully packed and labeled, and then shipped to their respective destinations.
Products Application
Precision grinding
Resinoid grinding wheels are widely used in precision grinding applications, such as tool and die making, aerospace, and medical devices.
Surface grinding
Resinoid grinding wheels are also commonly used for surface grinding applications, such as finishing metal parts, automotive components, and other industrial materials.
Cylindrical grinding
Resinoid grinding wheels are an excellent choice for cylindrical grinding applications, such as grinding gears, shafts, and other precision parts.
Cutting
Resinoid grinding wheels can be used for cutting applications, such as cutting metal sheets, tubes, and other industrial materials.
Our factory & quipment
Renwa Abrasive is one reliable manufacturer of abrasives and related industries, 20 years of experience make us one of the most potential companies in the abrasive fields.
Everything You Need to Know
What is the difference between resinoid grinding wheels and vitrified grinding wheels?
Resinoid grinding wheels are made of synthetic resin materials, while vitrified grinding wheels are made of glass material. Resinoid grinding wheels are suitable for high-speed grinding applications, while vitrified grinding wheels are more suitable for precision grinding.
What is the recommended speed for resinoid grinding wheels?
The recommended speed for resinoid grinding wheels is typically between 35 and 55 m/s. However, the speed may vary depending on the type of resinoid grinding wheel and the specific application.
What is the maximum operating temperature for resinoid grinding wheels?
The maximum operating temperature for resinoid grinding wheels is typically around 150°C. However, this temperature may vary depending on the specific resinoid grinding wheel and the application.
How can I choose the right resinoid grinding wheel for my application?
To choose the right resinoid grinding wheel for your application, you should consider the material to be ground, the required precision, the desired finish, and the operating conditions.
As one of the most professional resinoid grinding wheel manufacturers and suppliers in China, we're featured by quality products and competitive price. Please rest assured to buy or wholesale bulk resinoid grinding wheel in stock here from our factory.
