Cylindrical Mounted Point
Name: Cylindrical Mounted Point
Composition: PA,WA,A,GC
Appearance: Pink,black,green and so on
Size: Can be customized according to customer requirements
Payment:
30% T/T in advance for more than USD2000, balance pay before shipment.
100% T/T payment for amount less than USD2000.
Description
A cylindrical mounted point is a grinding tool that is cylindrical in shape. It consists of abrasive grains and binders, and common abrasive materials include silicon carbide, aluminum oxide, etc. It can be used for grinding, polishing, dressing and deburring and provides high precision and surface quality. The specific application depends on the characteristics and requirements of the mounted point, choose the appropriate specification and size for use. When using the mounted pointad, pay attention to personal safety and follow the relevant operating procedures.
Product Specification:
| Cylindrical shape mounted point (available size) | |||||
|
Code |
Diameter |
Height |
Diameter-pin |
|
|
|
(mm) |
(mm) |
(mm) | |||
|
A1 |
3 |
7 |
3 |
2.35 |
|
|
A2 |
4 |
10 |
3 |
2.35 |
|
|
A3 |
5 |
11 |
3 |
2.35 |
|
|
A4 |
6 |
12 |
3 |
2.35 |
|
|
A5 |
8 |
15 |
3 |
2.35 |
|
|
A6 |
10 |
15 |
3 |
2.35 |
|
|
A7 |
12 |
16 |
3 |
2.35 |
|
| Cylindtrical shape mounted point with Lengthened (available size) | |||||
|
Code |
Diameter |
Height |
Diameter-pin |
|
|
|
(mm) |
(mm) |
(mm) |
|||
|
A8 |
6 |
20 |
3 |
2.35 |
|
|
A9 |
7 |
20 |
3 |
2.35 |
|
|
A10 |
8 |
20 |
3 |
2.35 |
|
|
A11 |
9.5 |
20 |
3 |
2.35 |
|
|
A12 |
6 |
26 |
3 |
2.35 |
|
|
A13 |
7 |
26 |
3 |
2.35 |
|
|
A14 |
8 |
26 |
3 |
2.35 |
|
|
A15 |
9.5 |
26 |
3 |
2.35 |
|
Product Main Features:
1. Wear resistance
2. High grinding force
3. Strong handle fixed
4. Excellent balance control
Product Application:
1. Metal working: Cylindrical mounted point is widely used in the metalworking industry for grinding, polishing, dressing and deburring. They can be used to machine metal surfaces, edges and holes, providing the required precision and finish.
2. Welding repair: In the welding process, its can be used to repair the surface of welded joints, removing welding slag, oxides and uneven surface layers.
3. Woodworking: Its can also be used in woodworking for trimming, sanding and polishing the edges and surfaces of woodwork.
4. Mold manufacturing: During the mold manufacturing process, the it can be used to dress and grind the surface of the mold to improve the quality and precision of the mold.
5. Glass Processing: Cylindrical mounted point can be used in glass processing for cutting, grinding and polishing glass edges, holes and curved surfaces.
Product Packing:
FAQ:
Q: Samples are free?
A: Yes, we could provide samples with free of cost.
Q: How many days for sampling?
A: 7~10 days for regular size we have.
Q: How many days for production?
A: 30~60 days according to the size and quantity.
Q: Could we put our own logo?
A: Sure, customers logo can be made by laser engraved embossed transfer printing.
Hot Tags: cylindrical mounted point, China, manufacturers, suppliers, factory, wholesale, buy, price, in stock, high quality, free sample
